ERCO 401T

Built-in double-scissor lift

ERCO401T

Maximum accessibility and minimal space requirements for professional maintenance

Get a Quote
Brochure
Images

The ERCO 401T is Corghi’s recessed double scissor lift, designed for maintenance work on cars, SUVs, and light commercial vehicles. Thanks to its flush-floor installation, it offers an obstruction-free work area and greater convenience for daily operations.

The unit is equipped with an automatic MASTER/Slave hydraulic levelling system, safety devices with photoelectric sensors, and platforms with pull-out extensions to accommodate different types of vehicles.

Also available in the ERCO 351T version with a maximum capacity of 3,500 kg.

Benefits

Flush-mounted installation

Load capacity up to 4,000 kg

Automatic levelling

High operational safety

Features and functions

FLOOR-LEVELLED INSTALLATION

The recessed design ensures easy access to vehicles and makes the best use of workshop space.

MASTER/SLAVE HYDRAULIC SYSTEM

The two platforms remain constantly aligned thanks to the automatic hydraulic synchronisation system.

FOOTREST WITH REMOVABLE EXTENSION

The integrated extensions allow the bridge to be easily adapted to different wheelbases and lengths of vehicles.

SAFETY PHOTOCELL

If the platforms are misaligned, the system automatically stops the lift from operating.

Technical data

Type

Ponte sollevatore a doppia forbice ad incasso
Maximum flow rate

4.000 kg
Maximum lifting height

1.900 mm
Levelling system

Idraulico automatico MASTER/SLAVE
Footrests

Con estensione estraibile
Engine power

3 kW
Power supply

230-400 V 3Ph / 230 V 1Ph
Ascent/descent time

40 s
Type

Ponte sollevatore a doppia forbice ad incasso

Maximum flow rate

4.000 kg

Maximum lifting height

1.900 mm

Levelling system

Idraulico automatico MASTER/SLAVE

Footrests

Con estensione estraibile

Engine power

3 kW

Power supply

230-400 V 3Ph / 230 V 1Ph

Ascent/descent time

40 s
