FULLY AUTOMATIC
A top-of-the-range Corghi wheel balancer, it guarantees some of the fastest start-up and diagnostic times in the world, without requiring any manual intervention from the operator.
TOUCHSCREEN INTERFACE
The graphical user interface and touchscreen technology simplify and speed up operations and the selection of work programmes.
MACHINE VISION AND DIMENSION MEASUREMENT USING A CONTACTLESS SYSTEM
Without any operator intervention, EyeLight Plus, using a professional camera and advanced machine vision techniques (Corghi patent), captures and processes the image of the wheel, identifying its balancing planes. At the same time, two high-precision laser sensors carry out dimensional measurements on the wheel completely autonomously, without any contact (Contactless System), in a matter of seconds.
AUTOMATIC POSITIONING AND LED LIGHTING
At the end of the spin cycle, the wheel is braked and automatically moved into the balancing position (RPA). The integrated LED light illuminates the work area to facilitate the cleaning of the rim and the fitting of the balance weights.
APPLICATION OF ADHESIVE COUNTERWEIGHTS
The built-in dot laser indicates, with the utmost precision, where the adhesive counterweights should be applied.
COMPREHENSIVE WHEEL DIAGNOSTICS
The diagnostic programme automatically detects:
a) the point of maximum wheel eccentricity and guides the operator in positioning the wheel correctly on the hub, before tightening the bolts, to eliminate vibrations right from the fitting stage (BESTFIT);
b) the radial and lateral eccentricity of the wheel (1st harmonic and peak-to-peak) to calculate the best fit between the components, thereby resolving typical road vibration issues (FAST-MATCHING); c) wheel drift, which causes the vehicle to veer constantly towards one side of the road whilst travelling in a straight line; d) tread depth in three areas of the tyre
INTELLIGENT POSITIONING
A specialised diagnostic tool for vehicle wheel sets, designed to check tread wear, toe angles, eccentricity and imbalances. Once all the wheels have been programmed into the system, EyeLight Plus suggests the best way to position them on the vehicle to optimise comfort and safety.
WEIGHT MANAGEMENT PLUS
Reduce working time by up to 20 per cent and the use of counterweights by up to 30 per cent, delivering immediate economic and environmental benefits. A programme designed for those seeking faster and more sustainable balancing. Thanks to the three on-screen counters, you can monitor the savings in weight, time and money in real time.
WEIGHT: AUTOMATIC (HIDDEN)
New “Hidden Weight Automatic” programme to split the adhesive balancing weight on the outer side into two equivalent weights, positioned out of sight behind the spokes, entirely automatically.
